Installation and start-up of INGENIO PLUS UPS 30÷40 kVA
Installazione e avviamento INGENIO PLUS UPS 30÷40 kVA
OMS02082 REV. D
29
Rated current (at full load and battery recharging)
Power (kVA) 30 40
Rectifier input [A]
(1)
58 73
Bypass input / Output [A]
(1) (2)
44 58
Battery [A] 50 67
(1)
Values referred to 400Vac rated voltage
(2)
For the overload values refer to the Technical Specification
4.2 BACKFEED PROTECTION DEVICE
The INGENIO PLUS UPS is provided of a 230Vac voltage to operate the shunt trip coil of the
external sectioning device; the external device is not part of the UPS supply and is provided and
installed at customer care.
The following table shows the main electrical characteristics of the external sectioning device.
Backfeed protection device
Power (kVA) 30 40
Maximum operating voltage (Vac) 690
Minimum rated current (A) 50 63
Category AC-1
An isolator switch with integrated undervoltage release can be installed inside the UPS as an
option.
