Installation and start-up of INGENIO PLUS UPS 30÷40 kVA
Installazione e avviamento INGENIO PLUS UPS 30÷40 kVA
30 OMS02082 REV. D
4.3 TERMINAL BOARDS
The INGENIO PLUS UPS 30÷40 kVA is provided with terminal boards for the connection of
power cables and of auxiliary connections.
+B
N
-B
2-L1 2-L2 2-L3
1-N
1-L1 1-L2 1-L3
3-N
3-L1 3-L2 3-L3
2-L1 2-L2 2-L3
2-N
EXTERNAL
BATTERY
OPTIONAL
INPUT INTERNAL
ISOLATION
TRANSFORMER
OPTIONAL
BYPASS
INPUT
OPTIONAL
RECTIFIER
INPUT
UPS
OUTPUT
DIESEL MODE
AUXILIARY TERMINALS
TERMINALS
CONTATTO
AUX
BACK FEED
X11 F - N
XD 1-2
BAC 1 BAC 2
BCB EXTERNAL
OPTIONAL
Picture 6 – Terminal board INGENIO PLUS 30 kVA
