Accessories
Auxiliary handle * 6mm Allen wrench *
Wheel guard * 7/8˝ Arbor nut *
Foot plate * 1˝ Arbor nut *
Inner flange * 20mm Lock nut **
Outer flange * 22mm Open end wrench **
3/8” Allen wrench * Metal case **
(*= standard equipment) (**= optional accessories)
-13-
If an extension cord is
necessary, a cord with
adequate size conductors that is capable
of carrying the current necessary for your
tool must be used. This will prevent
excessive voltage drop, loss of power or
overheating. Grounded tools must use 3-wire
extension cords that have 3-prong plugs and
receptacles.
NOTE: The smaller the gauge number, the
heav i er the cord.
RECOMMENDED SIZES OF EXTENSION CORDS
120 VOLT ALTERNATING CURRENT TOOLS
!
WARNING
Extension Cords
Tool’s
A
mpere
Rating
Cord Size in A.W.G.
Wire Sizes in mm
2
3
-6
6-8
8-10
1
0-12
12-16
1
8 16 16 14 0.75 0.75 1.5 2.5
18 16 14 12 0.75 1.0 2.5 4.0
18 16 14 12 0.75 1.0 2.5 4.0
16 16 14 12 1.0 2.5 4.0 —
1
4 12 —— ————
25 50 100 150 15 30 60 120
C
ord Length in Feet
C
ord Length in Meters
