Bosch 200 Series Installation Manual

VG4 Modular Camera Series Table of Contents | en 5
Bosch Security Systems, Inc. Installation Manual F.01U.216.010 | 8.0 | 2011.02
6 Alarms and Relay Connections 98
6.1 Alarm Inputs 98
6.2 Configuring Supervised Alarms (inputs 1 and 2) 98
6.2.1 Configuring a Normally Open Supervised Alarm 98
6.2.2 Configuring a Normally Closed Supervised Alarm 99
6.3 Configuring Non-supervised Alarms (inputs 1 through 7) 99
6.3.1 Configuring a Normally Open Non-supervised Alarm 99
6.3.2 Configuring a Normally Closed Non-supervised Alarm 100
6.4 Alarm Outputs 100
6.4.1 Configuring a Dry Contact Relay 100
6.4.2 Configuring an Open Collector Output 100
7 Bubble Handling and Cleaning 101
7.1 Handling 101
7.2 Cleaning 101
7.2.1 Cleaning the Bubble Interior 101
7.2.2 Cleaning the Bubble Exterior 101
A Installation Notes for AutoTracker 102
A.1 Camera Height 102
A.2 Mount/Mounting Surfaces 103
A.3 Field of View 103
A.4 Unwanted Motion 103
Index 104

Bosch 200 Series Specifications

General

Series	200 Series
Category	Security Camera
Lens Type	Fixed
Night Vision	Yes
Weather Resistance	IP66
Power Supply	12V DC
Operating Temperature	-30°C to 50°C
Storage Temperature	-30°C to 60°C
