Bosch 4022 - Notes

56
H
NTC Removal
Fig. 14-11 Fig. 14-12
As demonstrated in Figs. 14-11 and 14-12, raising the Tank provides the necessary access space
required to remove either the NTC or the Circulation Pump / Motor.
Service note: When re-seating the Tank make sure to check that it is inserted squarely back into the
pump and seated properly.
