Specifications
Rating 120V
Amperage 15
No Load RPM 5,500
Blade Diameter (in.) 8-1/4"
Arbor Size 5/8"
Depth of Cut (in.)
at 90° 2-15/16"
at 50° 1-5/8"
at 45° 1-3/4"
Length (in.) 12"
Weight (lbs.) 13
Includes
24-Tooth Carbide-Tipped Blade ...Included
Blade Wrench ......................... 2 610 351 201
Optional Equipment
Rip Fence ................................ 2 610 025 341
Metal Case .............................. 3 605 438 539
Features
• 15 Amp ball bearing motor, 5,500 RPM
• Precision cut helical steel gears
• Large, easy-to-reach adjustment levers
• 60° bevel capacity with positive stop at 45°
• High-strength, alloy steel footplate
• Built-in blade wrench storage
• Footplate scale
• Spindle lock
1656
8-1/4" Circular Saw
See pages 95–102 for
circular saw accessories.
BOSCH
Circular Saws
Unmatched Accuracy, Power, and Durability
Combine for Long-Lasting Performance.
Taller, deeper gear teeth maximize contact and raise load
capacity, generating massive strength for even the most
demanding jobs. Left-sided blade placement clears your
line of sight, and a rigid motor housing eliminates blade
wobble for accurate cuts, every time. Independent testing
proves that the Worm Drive gear design lasts four times
longer than any conventional design to date.
Worm Drive Construction Saws
The Industry
Standard.
Redefined.
Specifications
Rating 120V
Amperage 15
No Load RPM 4,400
Blade Diameter (in.) 7-1/4"
Arbor Size Diamond Arbor
Depth of Cut (in.)
at 90° 2-3/8"
at 50° 1-13/16"
at 45° 1-15/16"
Weight (lbs.) 14
Includes
24-Tooth Carbide Blade .................WD724B
Optional Equipment
Extension Cords ........................ XC25, XC50
Rip Fence ...........................................WD7RIP
Features
• Powerful 15 amp all ball-bearing motor
• Direct Connect™ Cord Management System - Saves
user time and money on jobsite with no end-plug
snagging, easy cord repairs, and easy tool storage.
• Left side blade view - For unmatched line of sight
and blade visibility
• Saw hook - For easy storage between cuts
• Anti-snag lower guard - To minimize snagging
in wood
• Die cast magnesium footplate - For greater strength
• 50° bevel capacity with positive stop at 45°
• Magnesium housing
• Easy serviceable brushes
• Texture soft grip
• Spindle Lock
1677MDT also features
• Twist lock plug
1677MD(T)
7-1/4" Worm Drive Construction Saw
See pages 95–102 for
circular saw accessories.
BOSCH
XC25 25-FT. 12/3 AWG
Contractor Extension Cord
XC50 50-FT. 12/3 AWG Contractor Extension Cord
