English–7
0 275 U07 XPX | (8.2.18) Bosch eBike Systems
Product Features PowerTube
All representations of bike components, with the exception
of the battery packs and their holders, are schematic and
can deviate from your eBike.
3 Operation and charge-control indicator
4 On/Off button
5 Key for the battery pack lock
6 Battery pack lock
11 Battery charger
12 Socket for charge connector
13 Charge socket cover
14 PowerTube safety restraint
15 PowerTube battery
16 PowerTube safety hook
11
12 13
14
15
14
4
3
4
16 5
6
