Bosch eBike Systems 0 275 U07 XPX | (8.2.18)
Technical Data
Assembly
Put the battery pack down only on clean surfaces. In
particular, avoid getting the charge socket and the con-
tacts dirty, e.g., with sand or soil.
Checking the Battery Pack Before Using for the
First Time
Check the battery pack before charging it or using it with
your eBike for the first time.
To do this, press the On/Off button 4 to switch on the bat-
tery pack. If no LED for the charge-control indicator 3 lights
up, then the battery pack may be damaged.
When at least one of the LEDs, but not all, for the charge-
control indicator 3 is lit, then fully charge the battery pack
before using it for the first time.
Do not attempt to charge or use a damaged battery
pack. Please contact an authorized Bosch eBike dealer.
Charging the Battery Pack
Only use the Bosch charger provided with your eBike
or an identical original Bosch charger. Only this char-
ger is matched to the lithium-ion battery pack used in
your eBike.
Note: The battery pack is supplied partially charged. To
ensure full battery pack capacity, completely charge the
battery pack in the charger before using it for the first time.
To charge the battery pack, read and follow the operating
instructions for the charger.
The battery can be charged at any level of charge. Interrupt-
ing the charging process does not damage the battery pack.
The battery pack is equipped with a temperature control in-
dicator, which enables charging only within a temperature
range between 32 °F and 104 °F.
When the battery pack is not within the
charging temperature range, three
LEDs of the charge-control indicator 3
flash. Disconnect the battery pack from
the charger until its temperature has ad-
justed.
CAUTION: Do not connect the battery pack to the
charger until it has reached the permissible charging
temperature.
Lithium-ion battery pack PowerPack 400 PowerPack 500 PowerTube 500
Product code
BBS261/BBS266
S)
BBR261/BBR266
R)
BBS271/BBS276
S)
BBR271/BBR276
R)
BBP280 – horizontal
BBP281 – vertical
Rated voltage
V= 36 36 36
Rated capacity
Ah 11 13.4 13.4
Energy
Wh 400 500 500
Operating temperature
°F +23...+104 +23...+104 +23...+104
Storage temperature
°F +14...+140 +14...+140 +14...+140
Permitted charging temperature
range
°F +32...+104 +32...+104 +32...+104
Weight, approx.
lb 5.5/5.7 5.7/6.0 6.2
IP 54 (dust and splash
water protected)
IP 54 (dust and splash
water protected)
IP 54 (dust and splash
water protected)
Degree of protection
S) Standard battery pack
R) Rack-type battery pack
This device is in compliance with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device must not cause harmful interference, and
(2) this device must accept any interference that is received, including interference that may cause undesired operation.
This device is in compliance with CAN ICES-3(B)/NM B-3(B).
