English – 13
eBike and the eBike is switched on, then the on-board
computer's internal battery is powered and charged
by the eBike battery.
If the on-board computer is removed from the
holder(4), the power is supplied by the internal bat-
tery of the on-board computer. The state of charge of
the internal battery of the on-board computer is dis-
played in the top left corner of the statusbar.
If the charge of the on-board computer's internal bat-
tery is running low, a warning message appears on
the display.
To charge the on-board computer's internal battery,
slide the on-board computer back onto the
holder(4). Note that if you do not charge the eBike
battery straight away, the eBike will automatically
switch off after tenminutes of inactivity. If this hap-
pens, the on-board computer's internal battery will
also stop charging.
You can also charge the on-board computer via the
USB port(8). To do this, open the protective cap(2).
Use a Micro USB cable to connect the USB port on the
on-board computer to a commercially available USB
charger (not included with the product as standard)
or to the USB port of a computer (max. 5V charging
voltage; max. 1500mA charging current).
If the internal battery of the on-board computer is not
recharged, the date and time will be retained for ap-
prox. 6months.
Note: To maximize the service life of the on-board
computer's internal battery, it should be recharged
for onehour every three months.
Following use, the USB port must be carefully re-
sealed with the protective cap(2).
u A USB connection is not a watertight plug con-
nection. When cycling in wet conditions, ensure
no external devices are connected and that the
USB port is fully covered by the protective
cap(2).
It is not possible to charge external devices via the
USB port.
Battery charge indicator of the eBike
battery
The battery charge indicator for the eBike batteryg
(see "<Ride Screen>", pageEnglish – 18) can be
read on the statusbar. The eBike rechargeable bat-
tery's state of charge is also indicated by the LEDs on
the eBike rechargeable battery itself.
Color of the indicator Meaning
Green The eBike rechargeable
battery is over 30%
charged.
Orange The eBike rechargeable
battery is charged be-
tween 15% and 30%.
Red The eBike rechargeable
battery is charged be-
tween 0% and 15%.
Red+! The capacity for assisting
the drive has been used
up, and assistance is
switched off. The remain-
ing capacity will be pro-
vided for the bike lights
and the on-board com-
puter.
If the eBike battery is being charged on the eBike, a
corresponding notification will be displayed.
If the on-board computer is removed from the
holder(4), the state of charge that was last displayed
for the eBike rechargeable battery is saved.
Starting operation of the on-board
computer
u Prior to initial start-up, remove the protective
film from the display to guarantee that the on-
board computer is fully functional. If the protec-
tive film remains on the display, this can impact the
functionality/performance of the on-board com-
puter.
Bosch eBike Systems 1 270 U20 BN2 | (14.03.2023)
