Bosch B24CB80ESS - Removing the Fittings

en-us Cleaning and maintenance
16
15.3 Removing the fittings
If you want to clean the fittings thoroughly, remove these
from your appliance.
Removing the shelf
▶ Lift the shelf at the front , pull it out and remove it ⁠.
Removing the storage container
1. Pull the storage container out all the way.
2. Lift the storage container at the front and remove it
⁠.
Removing the fruit and vegetable container
1. Pull out the fruit and vegetable container as far as it will
go.
2. Lift the fruit and vegetable container at the front and
remove it ⁠.
Removing the frozen food container
1. Pull out the frozen food container as far as it will go.
2. Lift the frozen food container at the front and remove
it ⁠.
Removing the front of the container
You can remove the front of the fruit and vegetable con-
tainer and frozen food container to facilitate cleaning.
