en | Keypads overview Control panels
2018.07 | 01 | F.01U.352.527 Bosch Sicherheitssysteme GmbH
3
Keypads overview
3.1
B94x keypad
3.1.1
Housing and display
GAS
HH:MM
DD/MM/YYYY
1
2
4
5
6
7
3
No. Component Description
1 Power Indicates power status.
2 Feature key Performs specific programmed function.
3 Status icons Refer to Status icons, page 10.
4 Display Refer to Idle screen, page 11.
5 Ribbon bar Refer to Ribbon bar, page 9.
