14
|
Bosch Climate 5000 Series Wired Wall Thermostat User Manual
06.2019 | Bosch Thermotechnology Corp.
Data subject to change
2. Press and hold the Mode button to activate the automatic lift function. The
faceplate icon will fl ash. F2 will be shown on the display when the grille can
be adjusted.
Figure 39
3. Press + or - to control the lift up and down functions of the grille. While grille
lifts down, press + to stop. While grille lifts up, press - to stop.
Figure 40
Lower Raise
-
+
6.10 Swing Function
Louver Up-Down (applicable to Wall mounted and Cassette Indoor models only)
1. The louver swings by six degrees every time when the Swing button is
pressed.
2. Press and hold Swing for 2 seconds to activate auto swing mode. Press
Swing again to deactivate.
Swing
3. When the auto swing mode is activated, the fan swing icon will appear on
the display.
Figure 41
