Bosch C 950 - Page 78

Interior components diagram and parts list
C 950/C 1050 (Pro TL 175 C/199 C) – 6 720 805 440 (2019/10)
78
Table 56
Item Description Reference
1 Heat exchanger (LP Gas) 8 738 704 026 0
1 Heat exchanger (Natural Gas) 8 738 704 117 0
2 Heat exchanger top gasket 8 704 701 052 0
3 Condensing exchanger inlet 8 705 700 159 0
4 Overheat sensor (ECO) 8 707 206 204 0
5 Heat exchanger bottom gasket 8 704 701 054 0
6 Sight window 8 701 000 401 0
7 Ignition group 8 701 302 249 0
8 Heat exchanger O-ring 8 700 205 147 0
9 Rubber grommet 8 710 303 027 0
10 Connecting pipe 8 700 715 493 0
11 Pipe connection clip 8 701 201 028 0
12 Condensing exchanger gasket 8 704 701 090 0
13 Condensing exchanger nut 8 703 301 157 0
14 Condensing heat exchanger 8 705 700 161 0
15 Condensing exchanger left side 8 705 700 162 0
16 Condensing exchanger side 8 704 701 091 0
17 Allen screw 2 918 060 162 0
18 Condensing exchanger right 8 705 700 163 0
19 Screw 2 910 611 496 0
20 Fincoil O-ring 8 700 205 226 0
21 Condensing fincoil 8 700 715 402 0
22 O-ring 8 700 205 228 0
23 Condensate drain connector 8 705 506 838 0
24 Condensate drain connector 8 704 701 092 0
25 Exhaust temperature sensor 8 707 206 459 0
26 Washer 8 704 701 097 0
27 U-bend pipe 8 703 305 352 0
28 Condensing exchanger clip 8 701 300 023 0
30 Flue gas collector 8 705 506 841 0
31 Cold water pipe upper 8 700 715 398 0
32 Siphon 8 705 202 141 0
33 Condensate drain pipe 8 700 703 177 0
34 Condensate drain pipe clip 8 716 102 607 0
35 Condensate drain pipe O-ring 8 704 701 094 0
36 Insulation (145x60) 8 702 303 027 0
37 Washer 8 704 701 088 0
38 Temperature Sensor 8 700 400 040 0
39 O-ring 8 700 205 310 0
Item Description Reference
