13 | english
August 2009 | C3 | Battery charger Automotive Aftermarket
List of parts
1 Charger
2 Mounting hook
3 Power cord with mains connector
4 Charging cable with cable lug
(red and black)
5 (+) Terminal (red)
6 (–) Terminal (black)
7 Standby / power indicator
8 Mode selection button
9 Reverse polarity protection
10 Charge status
11 Charge status “ok” (lit)
Charge maintenance (flashing)
12 Mode 1 | 6 V (charging)
13 Mode 2 | 12 V (charging motorcycle)
14 Mode 3 | 12 V (charging car)
15 Mode 4 | 12 V (charging winter, AGM)
16 12 V operation indicator
Technical data
Primary
Rated
input voltage: 230 V / 50 Hz
Starting current: < 50 A
Rated input current: max. 0.6 A (rms value)
Power input: 60 W
Secondary
Rated output voltage: 6 V
12 V
Charging voltage: 14.7 V (± 0.25 V),
14.4 V (± 0.25 V),
7.2 V (± 0.25 V)
Charging current: 3.8 A (± 10 %),
0.8 A (± 10 %)
Rated output current: 0.8 A / 3.8 A
Ripple
1
: max. 150 mV
Backflow current
2
: < 5 mA (no AC input)
Degree of protection: IP 65 (dustproof, water-
tight)
Battery type: 6 V + 12 V lead acid
battery (AGM, GEL, open
and VRLA)
Battery capacity: 6 V:1.2 Ah–14Ah /
12 V:1.2 Ah–120 Ah
Fuse (internal): 1.6 A
Noise level: < 50 dBA
Ambient
temperature: 0 to + 40 °C
Dimensions: 185 x 81 x 55 mm
(L x W x H)
