Bosch C30 charger I Operating instructions EN
12
1 Charger
2 Mounting hook
3 Mains cable with mains connection
4 Charging cable with cable lug
(red and black, 18AWG cable)
a Fuse holder with fuse
b Plug
5 (+) Terminal clamp (red)
6 (–) Terminal clamp (black)
7 Standby
8 Mode selection button
9 Reverse polarity protection + -
10 Battery capacity indicator
Battery capacity: 100%
Battery capacity: 75%
Battery capacity: 50%
Battery capacity: 25%
11 Mode 1 | 12 V (car)
12 Mode 2 | 12 V (motorcycle)
13 Mode 3 | 12 V (charging at
0-4°C in winter or AGM)
14 Mode 4 | 12 V
(regeneration)
15 Mode 5 | 6 V (motorcycle)
Device description
(1)
(6)
(5)
(4)
(4b)
(4a)
(3)
(2)
(4a)
(4a)
(8)
(7)
(( 9)
(15)
(14)
(13)
(12)
(11)
(10)
