EN Bosch C30 charger I Operating instructions
13
1 Technical data
Technical data
Input voltage
230VAC / 50Hz
Starting current <50 A
Rated input current Max. 0.6 A (RMS value)
Input power 60 watts
Rated output voltage DC 6 V/12 V
Charging voltage 14.7 V (± 0.25 V), 14.4 V (± 0.25 V),
7.2 V (± 0.25 V), 16.5 V (± 0.5 V)
Charging current 3.8A (± 10%), 0.8A (± 10%), 1.5 A (± 0.3 A)
Rated output current 0.8 A, 3.8 A
Reverse current1 < 5 mA (no AC input)
Protection rating IP65 (dustproof, waterproof)
Battery type 6 V & 12 V lead-acid battery (WET, EFB, GEL, AGM
and open VRLA)
Battery capacity 6 V: 1.2 Ah – 14 Ah, 12 V: 1.2 Ah – 120 Ah
Fuse (internal) 3.15 A
Fuse (fuse holder) 10 A
Noise level < 50 dB(A)
Temperature 0°C to + 40°C
Dimensions 169 x 81 x 54 mm (L x W x H)
1)
The reverse current is the current that the charger consumes from the battery when no mains
power is connected.
