Table 14: Zone Status Display Descriptions
Number
Displayed
Zone
Description
0
Zone Normal
Indicates the corresponding zone is in
the sealed state.
1
Alarm
Indicates the corresponding zone is
unsealed and in alarm condition.
2
Zone Bypassed
Indicates a system operator manually
isolated the corresponding zone. See
Section 8. Isolating Zones for
information on how to manually isolate a
zone(s) prior to arming the system.
3
Zone Trouble
Indicates a zone was left unsealed after
the end of exit time.
System Status
The system status information is divided into four
digits.
Table 15: System Status
System Status
Display
Description
First digit Indicates whether the system is
armed or disarmed:
8 = Disarmed
9 = Armed
Second digit Indicates which codepad alarm was
triggered by the operator:
0 = No Codepad Alarm
1 = Codepad Panic or Duress
Alarm
2 = Codepad Fire Alarm
3 = Codepad Medical Alarm
Third digit Indicates when the AC mains
supply fails:
0 = AC Supply is normal
1 = AC Supply has failed
Fourth digit Indicates when a system fault
occurs at the control panel:
0 = System Normal – There are no
faults
1 = System Fault – There is a fault
registered by the control panel
Figure 7 shows that the transmission came from the
control panel with ID number 678, and that zone
2 is in alarm. The figure also shows that zone 3
was manually isolated and the system armed.
