Operation
Climate 5000M/L • Climate 5000i M/U – 6721855980 (2023/05)
44
The fan speed cannot be adjusted in automatic mode.
Cooling mode
▶ Press Mode key repeatedly until appears on the display.
▶ Press the key until the required air speed is reached.
▶ Select the required temperature with the . and / keys.
Fan (Only) mode
▶ Press Mode key repeatedly until appears on the display.
▶ Press the key until the required fan speed is reached. AUTO can
be selected to enable automatic control.
The temperature cannot be adjusted or displayed in fan mode.
Dehumidification mode
▶ Press Humidity key repeatedly until appears on the display.
▶ Set the required temperature with the . and / keys.
The fan speed cannot be adjusted in dehumidification mode.
Heating mode
▶ Press Mode key repeatedly until appears on the display.
▶ Set the required temperature with the . and / keys.
▶ Press the key until the required fan speed is reached.
If the outside temperature is very low, the heating capacity of the air
conditioning system may not be sufficient. We recommend connecting
additional heat sources.
3.5 Setting timer
ON and OFF timers can be set to between 0 and 24 hours, in 30-minute
increments for the first 10 hours, then in 1-hour increments. If 0 hours is
set, the timer is cancelled.
Setting the on timer
▶ Press the key until the symbol appears.
▶ Press the . or / key to set the desired time.
The setting is applied shortly afterwards.
Setting the off timer
▶ Press the key until the symbol appears.
▶ Press the . or / key to set the desired time.
The setting is applied shortly afterwards.
Cancelling timer
▶ Press the key to select the corresponding timer.
▶ Set 0.0 hours.
The timer is cancelled after a short time.
Combining timers
The two timers can be set at the same time. Either timer can be
programmed to activate prior to the other
▶ Set the on timer and off timer.
The settings will be automatically combined.
Table 44 Example
You can not program the on timer and off timer to operate the unit at
different temperatures or with other settings.
3.6 Other functions
3.6.1 Setting the swing function
Because cold air flows downwards and hot air flows upwards, you can
improve the cooling and heating effect as well as the air distribution by
adjusting the air flow direction on the upper air outlet grille.
Notice on air flow direction:
▶ Choose the vertical outlet for heating mode. The indoor temperature
will not be uniform in heating mode when the air-out direction is
horizontal.
▶ Choose the horizontal outlet mode for cooling.
To achieve an optimum cooling or heating effect, the air outlet direction
can be manually adjusted horizontally or vertically at the touch of a
button.
▶ Keep the Swing button pressed until the air outlet grille is in the
desired position.
When cooling
▶ Set the air outlet grille downwards (horizontal) ( Figure 2).
When heating
▶ Set the air outlet grille horizontal ( Figure 3).
NOTICE
▶ Do not adjust the upper air outlet grille by hand as this may cause
malfunctions and condensation to form on the air outlets.
Adjusting the lower air outlet grille
To fulfil the ambient temperature conditions, the lower air outlet grille
can be opened when the unit is switched on.
▶ Operate the appliance.
▶ Remove the cover of the electronics ( Figure 4, [1]).
▶ Press button [2] for 5 seconds within 10 minutes after switching on,
in order to change to standby mode.
▶ Press the button again to open or close the lower air damper.
While the lower air outlet grille is being adjusted, the indoor unit display
shows the status of the adjustment button.
on: lower air inlet grille open
off: lower air inlet grille open
3.6.2 Changing over display and alarm buzzer (Mute ModeMute
Mode)
▶ To switch on or off the display at the indoor unit and the alarm buzzer:
press LED key.
▶ To display the current room temperature, press the LED key and hold
for 5 seconds.
▶ To display the set temperature: press and hold the LED key for
another 5 seconds.
Current time 13:00 o'clock
Setting of ON timer 4.0 h
Setting of OFF timer 8.5 h
Switch-on time 17:00 o'clock
Switch-off time 21:30 o'clock
