en Control panel
Control panel
Information is shown on the display or
settings can be entered by touching the
touchscreen and the control ring�
Display
The control panel shows the selected
drinks, settings and setting options, as well
as messages about the appliance’s operat-
ing status�
e�g� Drink selection
Y very strong
Ristretto
high O
R 25 ml off ^
e�g� Information
Water tank
almost empty
Information disappears after operating the
appliance or after a short time�
The information remains however in the
information display in the form of a small
symbol�
a
Bean container almost empty
b
Water tank almost empty
c
Replace water filter
d
Cleaning programme necessary
e
Descaling programme necessary
f
Calc'nClean programme necessary
Prompts to take action
Fill
water tank
F
If the action required was carried
out, e�g� filling the water tank, the
corresponding message and symbol
will disappear�
Operation
Touch texts or symbols combined with
turning the control ring to navigate in the
control panel (for an example, see section
“Drink adjustment”)�
An audible signal is heard when touching
the touch display� These audible signals
can be switched on or o󰀨 (see the section
“Menu – Key tones”)�
Preparing drinks
This fully automatic co󰀨ee machine can
be operated using co󰀨ee beans or ground
co󰀨ee (but not instant co󰀨ee).
If using co󰀨ee beans, they will be freshly
ground for each brewing� For optimum
quality, store the beans in a cool place in
sealed containers�
F
Important: Fill the water tank with
fresh, uncarbonated, cold water
every day� The tank should always
contain sufficient water for operating
the appliance�
Tip: Cups should be prewarmed, e�g�
with hot water� This applies particu-
larly to small thick-walled espresso
cups�
For some settings, coffee is pre-
pared in two stages (see the section
“Aroma Double Shot” and “Two
cups at once”)� Please wait until the
process is completely finished�
Beverage selection
Turn the control ring to select di󰀨erent
drinks: The symbol and the name of the
selected drink will appear in the middle of
the information display�

Bosch CTL636ES6 Specifications

General

Product type	Espresso machine
Built-in grinder	Yes
Capacity in cups	- cups
Milk adding type	Automatic
Number of spouts	1
Coffee input type	Coffee beans
Coffee maker type	Fully-auto
Appliance placement	Built-in
Water tank capacity	2.4 L
Coffee beans capacity	500 g
Maximum operating pressure	19 bar
Reservoir for brewed coffee	-
Cord length	1.7 m
Display type	TFT
Product color	Black, Stainless steel
AC input voltage	220–240 V
AC input frequency	50 - 60 Hz
Package depth	670 mm
Package width	475 mm
Package height	545 mm
Package weight	22420 g

Weight and Dimensions

Depth	375 mm
Width	594 mm
Height	455 mm
Weight	19440 g
Installation compartment depth	356 mm
Installation compartment width	558 mm
Installation compartment height	449 mm
