1 689 989 473 | 2021-08-24Robert Bosch GmbH
2.6 Foreseeable misuse
Misuse ( ) with corresponding intended use ( ):
 Use of diesel fuel and instead of test oil.
 Only use test oil complying with ISO 4113-CV-AW.
---Separator---
 Failure to observe maintenance intervals.
 Perform maintenance according to the specied
maintenance intervals.
---Separator---

Use of manually created test sequences with incor‐
rect parameters.

Only use the test sequences specied by Bosch.
---Separator---
 Setting incorrect calibration values.

Enter correct calibration values.
---Separator---
 Use outside the allowed ambient conditions.
 Use the DCI 700 only under the allowed ambient
conditions.
---Separator---

Testing of damaged injectors or injectors that have
not been cleaned.

Prior to clamping, test and clean the injectors as
specied.
---Separator---
2.7
Warranty and liability
The use of unapproved hardware and software will re‐
sult in a modication of our products and thus to the
exclusion of any liability or warranty, even if such hard‐
ware and software have been removed or deleted again
in the interim.
No modications may be carried out on our products.
Our products may only be used with genuine accesso‐
ries and genuine spare parts. Otherwise, all warranty
claims will be rendered null and void.
This product may only be operated using operating sys‐
tems approved by Bosch. If the product is operated
with an operating system other than the one approved,
then the warranty obligation expires in accordance with
our terms of delivery. Furthermore, no liability can be
assumed for damages and consequential damages that
have their cause in the use of an operating system that
has not been released.
---
2.8
Protective clothing and equipment
•
Safety goggles
•
Safety shoes
•
Protective gloves
When working on the DCI 700, always wear your per‐
sonal protective clothing and equipment.
---
3.
Product description
---
3.1
Scope of delivery
Denomination Order number
DCI 700 -
1x parts set with monitor, mounting and key‐
board shelf
1 685 200 173
Denomination Order number
1x cable gland for cable diameters of 13 to
18 mm
1 683 391 564
1x adapter nut for cable gland 1 680 365 012
1x parts set with 4 injector chamber devices 1 687 016 196
4x knurled nut D7 1 683 373 087
4x O-ring insert D7 without O-rings 1 680 109 141
40x O-ring 12 x 2 mm for O-ring insert D7 and
D9
1 680 210 123
40x O-ring 7 x 4 mm for O-ring insert D7 1 680 210 124
40x O-ring 9 x 3 mm for O-ring insert D9 1 680 210 132
4x hose assembly for the injected-fuel quanti‐
ty
1 687 410 056
4x hose assembly for the return quantity 1 680 712 382
4x return adapter for Bosch CRI 1 687 016 215
4x return adapter hose assembly for Bosch
CRI 2.18 and CRI 2.20
1 683 351 066
4x return adapter hose assembly for Bosch
CRI 3
1 680 712 315
4x adapter nut M14x1.5 1 683 345 066
2x storage tray 1 685 520 631
1x drain hose for emptying the heat exchanger 1 680 712 392
1x square box wrench 1 681 982 011
4x adapter cable for Bosch CRI 1, CRI 2x and
CRI 3x
1 684 465 900
4x adapter cable for Bosch CRI 3-25 and
CRI 3-27
1 684 465 895
1x protective hose yellow (450 mm) -
1x recovery USB stick 1 688 400 654
1x original instructions 1 689 989 473
1x installation instructions 1 689 978 630
---
The order numbers are not part numbers. The or‐
der numbers are used to identify the items inclu‐
ded in the scope of delivery. Components that
can be ordered are identied as spare parts or
wearing parts.
---
3.2
Optional accessories
•
1 687 010 607: accessory set for testing Bosch com‐
mercial-vehicle common-rail injectors (CRIN 1x, CRIN
2x, CRIN 3x)
•
1 687 010 608: accessory set for testing Bosch com‐
mercial-vehicle common-rail injectors (CRIN 4.2)
•
1 687 010 609: accessory set for common-rail injec‐
tors from third-party manufacturers (Delphi DFI, Den‐
so Gx and Siemens/VDO/Continental PCR-I)
•
1 685 200 178: holding device for hand scanner
More information: Website of Bosch Automotive
Service Solutions for conguring your test and re‐
pair equipment:
https://component-test.bosch-au-
tomotive.com/en/en/sharedActions/countrySelec-
tor .
---
DCI 700 | 5 | en
