Maintenance
Table 1: Dimensions
Model
Vertical
Unit
(In)
Horizontal
Unit
(In)
Supply Air
Connection
(In)
Return Air
Connection*
(In)
Replacement Fil-
ter Nominal Size*
(In)
Width Depth Height Width Depth Height Width Height Width Height
EP007 21.75 21.75 32.75 21.75 43.25 16.75 11.75 7.75
H: 20.25
V: 18.0
H: 13.0
V: 13.0
H: 15"x20"x1" (1)
V: 15"x20"x1" (1)
EP009 21.75 21.75 32.75 21.75 43.25 16.75 11.75 7.75
H: 20.25
V: 18.0
H: 13.0
V: 13.0
H: 15"x20”x1” (1)
V: 15"x20”x1” (1)
EP012 21.75 21.75 32.75 22.25 45.25 19.75 7.75 11.75
H: 20.25
V: 18.0
H: 16.0
V: 16.0
H: 18"x20”x1” (1)
V: 18”x20”x1” (1)
EP015 21.75 21.75 39.25 22.25 45.25 19.75 13.75 13.75
H: 20.25
V: 18.0
H: 16.0
V: 18.0
H: 18"x20”x1” (1)
V: 20"x20”x1” (1)
EP018 21.75 21.75 39.25 22.25 45.25 19.75 13.75 13.75
H: 20.25
V: 18.0
H: 16.0
V: 18.0
H: 18"x20"x1" (1)
V: 20"x20"x1" (1)
EP024 21.75 26.25 47.25 26.25 54.75 22.00 13.75 15.75
H: 30.25
V: 22.0
H: 18.0
V: 22.0
H: 20”x30”x1” (1)
V: 24"x24"x1” (1)
EP030 24.25 33.50 47.25 30.25 68.25 22.00 15.75 15.75
H: 35.0
V: 28.0
H: 18.0
V: 22.0
H: 20”x34.5”x1" (1)
V: 24"x30"x1" (1)
EP036 24.25 33.50 47.25 30.25 68.25 22.00 15.75 15.75
H: 35.0
V: 28.0
H: 18.0
V: 22.0
H: 20"x34.5"x1" (1)
V: 24"x30"x1" (1)
EP042 26.25 33.50 58.25 30.25 79.00 22.00 17.75 17.75
H: 48.25
V: 28.0
H: 18.0
V: 30.0
H: 24"x20"x1" (2)
V: 16"x30"x1" (2)
EP048 26.25 33.50 58.25 30.25 79.00 22.00 17.75 17.75
H: 48.25
V: 28.0
H: 18.0
V: 30.0
H: 24"x20"x1" (2)
V: 16"x30"x1" (2)
EP060 26.25 33.50 66.25 30.25 89.25 22.00 17.75 17.75
H: 56.25
V: 28.0
H: 18.0
V: 38.0
H: 28"x20"x1" (2)
V: 20"x30"x1" (2)
EP070 26.00 33.50 66.50 30.00 89.00 22.00 17.75 17.75
H: 56.25
V: 28.0
H: 18.0
V: 38.0
H: 28"x20"x1" (2)
V: 20"x30"x1" (2)
*H = Horizontal Unit; V = Vertical Unit
