EP Series
Subject to change without prior notice Revised 12-13
8733922168
Table 5: Fluid Pressure Drops
Model
Flow Rate
(GPM)
Pressure
Drop (FOH)
Pressure
Drop (PSI)
Model
Flow Rate
(GPM)
Pressure
Drop (FOH)
Pressure
Drop (PSI)
007
1 1.4 0.61
030
4 1.2 0.51
1.5 2.9 1.26 5.5 2.1 0.91
2 4.9 2.11 7 3.2 1.41
3 10.1 4.38 10 6.1 2.67
4 16.9 7.34 13 9.9 4.28
009
1.5 2.3 1.00
036
5 1.6 0.71
2 3.9 1.68 7.5 3.3 1.45
2.5 5.8 2.51 10 5.6 2.43
3.25 9.3 4.03 12.5 8.4 3.64
4 13.5 5.85 15 11.8 5.11
012
2 1.7 0.72
042
7 3.0 1.30
3 3.4 1.50 8.75 4.4 1.91
4 5.8 2.51 10.5 6.1 2.66
5.5 10.2 4.45 13.25 9.3 4.04
7 15.8 6.88 16 13.2 5.74
015
2 1.6 0.69
048
8 3.8 1.65
3 3.3 1.44 10.67 6.3 2.73
4 5.5 2.41 12 7.8 3.38
5.5 9.8 4.28 14 10.3 4.46
7 15.2 6.60 16 13.2 5.75
018
3 4.1 1.80
060
9 4.7 2.04
4 7.0 3.02 12 7.8 3.38
5 10.4 4.52 15 11.7 5.05
6.5 16.7 7.25 17.5 15.4 6.66
8 24.2 10.53 20 19.8 8.58
024
3 2.0 0.87
070
10 2.8 1.24
4.5 4.1 1.80 13.5 4.9 2.12
6 6.9 3.01 17 7.4 3.22
8 11.6 5.06 20.5 10.4 4.50
10 17.4 7.56 24 13.8 5.98
