MUX expansion module Description | en 11
Bosch Security Systems. Inc. 2016.10 | 1.0 | F.01U.330.684
2 Description
The FPE‑7039 MUX expansion module is designed to enhance
the conventional features of the D7024 or FPD-7024/DS9400
Fire alarm control panels (FACPs). The module connects directly
to the FACP for either two ClassB multiplex buses or one
ClassA multiplex bus. When installed as two ClassB multiplex
buses, you can program addresses 9 through 255. When
installed as one ClassA multiplex bus, you can program
addresses 9 through 128.
The module also increases the number of relay outputs (to 58
on the D7024/DS9400 control panels and 59 on FPD‑7024
control panels). It adds an additional 400 events to the history
buffer for a total of 499 non‑volatile events. It also allows for up
to 100 system users (an addition of 84 PINs from the base
system).
The module can be programmed remotely from a PC using RPS
Remote programming software.
The module can be used with the Bosch Security Systems, Inc.
control panels and modules indicated in the following table.
Control panels
Active: FPD-7024 Fire alarm control panels
Legacy:* D7024 Fire alarm control panels
DS9400 Control panels
Modules
Active: D7042 Multiplex eight-input remote module
D7042B Multiplex eight-input remote module
with enclosure
D7044 Multiplex single-input module
D7044M Multiplex mini single-input module
