Bosch GLM 30 User Manual

10 | English
1 609 92A 297 | (21.4.16) Bosch Power Tools
 Remove the batteries/rechargeable batteries from the measuring tool when
not using it for longer periods. When storing for longer periods, the batteries/re-
chargeable batteries can corrode and self-discharge.
Operation
Initial Operation
 Do not leave the switched-on measuring tool unattended and switch the mea-
suring tool off after use. Other persons could be blinded by the laser beam.
 Protect the measuring tool against moisture and direct sun light.
 Do not subject the measuring tool to extreme temperatures or variations in
temperature. As an example, do not leave it in vehicles for a long time. In case of
large variations in temperature, allow the measuring tool to adjust to the ambient
temperature before putting it into operation. In case of extreme temperatures or
variations in temperature, the accuracy of the measuring tool can be impaired.
 Avoid heavy impact to or falling down of the measuring tool. After severe exte-
rior effects to the measuring tool, it is recommended to carry out an accuracy
check (see “Accuracy Check of the Distance Measurement”, page 13) each time
before continuing to work.
Switching On and Off
To switch on the measuring tool, briefly press the measuring button 2. Measuring tool
and laser are switched on.
 Do not leave the switched-on measuring tool unattended and switch the mea-
suring tool off after use. Other persons could be blinded by the laser beam.
To switch off the measuring tool, press the measuring button 2 and hold it down.
Measuring Procedure (see figure A)
Once switched on, the measuring tool is in the length measurement mode.
The rear edge of the measuring tool is always the reference level for the measure-
ment.
Place the measuring tool against the desired starting point of the measurement (e.g.
a wall).
Briefly press the measuring button 2 to initiate the measurement. Then the laser
beam is switched off. To switch the laser beam on again, briefly press the measuring
button 2. To initiate a further measurement, briefly press the measuring button 2
again.
OBJ_BUCH-2099-004.book Page 10 Thursday, April 21, 2016 1:10 PM

Bosch GLM 30 Specifications

General

Accuracy	± 2 mm
Laser Class	2
Laser Type	635 nm, <1 mW
Power Supply	2 x 1.5 V LR03 (AAA)
Dimensions	105 x 41 x 24 mm
Measurement Time, typical	0.5 s
Measurement Time, max.	4 s
Automatic Deactivation	5 min
Operating Temperature	-10 – 50 °C
Protection Class	IP54
Measurement Range	0.15 – 30 m
Units of Measurement	m
Battery Life	5000 individual measurements
Display	Illuminated display
