Setting the unit of measure
m, cm
m, cm,
ft, in
(frac-
tions),
ft/in
(frac-
tions)
m, cm,
Tai-
wan ft
Measuring range (typical)
0.05–50 m
A)
Measuring range (typical
under unfavourable
conditions)
20 m
B)
Measuring accuracy
(typical)
±1.5mm
A)
Measuring accuracy
(typical under unfavoura-
ble conditions)
±3.0mm
B)
Lowest indication unit 0.5 mm
Indirect Distance
Measurement and Vial
Measuring range 0°–360° (4x90°)
Gradient measurement
Measuring range 0°–360° (4x90°)
Measuring accuracy
±0.2°
C)/D)/G)
Digital Laser Measure GLM 500
0.1°
General
Operating temperature –10 °C...+45 °C
E)
Storage temperature –20 °C...+70 °C
Relative air humidity, max.
90 %
Laser class
2
Laser type
635 nm, <1 mW
Laser beam diameter
(at 25 °C) approx.
–at 10m distance
–at 50m distance
9mm
D)
45 mm
D)
Automatic switch-off after
approx.
–Laser
– Measuring tool (without
measurement)
20 s
5min
Weight according to EPTA-
Procedure 01:2014
0.10 kg
Dimensions
106 x 45 x 24 mm
Degree of protection
IP 54 (dust and splash
proof)
F)
Batteries
Rechargeable batteries
2 x 1.5 V LR03 (AAA)
2x1.2VHR03(AAA)
Setting the sound
Digital Laser Measure
Lowest indication unit
(typical)
Product Features
The numbering of the product features shown refers
to the illustration of the measuring tool on the graphic
page.
A) For measurements from the front edge of the measuring
tool, applies to high reflectivity of the target (e.g. a white-
painted wall), weak backlighting and 25 °C operating temper-
ature. In addition, a deviation of ± 0.05mm/m must be taken
into account.
B) For measurements from the rear measuring tool edge, ap-
plies to high reflectivity of the target (e.g. white cardboard),
strong backlighting and – 10 °C to +45 °C operating temper-
ature. In addition, a deviation influence of ±0.15 mm/m must
be taken into account.
C)
After user calibration at 0 ° and 90 °; An additional grade
error of ±0.01 °/degree to 45 ° (max.) has to be taken into ac-
count. The left-hand side of the measuring tool serves as the
reference level for grade measurement.
D) At 25 °C operating temperature
E) In the continuous measurement function, the maximum op-
erating temperature is +40 °C.
F) except battery compartment
G) The left-hand side of the measuring tool serves as the refer-
ence level for grade measurement.
The measuring tool can be clearly identified with the serial
number 11 on the type plate.
1 Display
2 Measuring button[ ]
3 Plus button[+]
4 Button for selection of the reference level
5 On/Off button[ ]
6 Menory button[ ]
7 Function button[Func]
8 Minus button[–]
9 Battery lid
10 Latch of battery lid
11 Serial number
12 Laser warning label
13 1/4"- Tripod socket
14 Reception lens
15 Laser beam outlet
16 Protective pouch*
17 Laser target plate*
18 Laser viewing glasses*
19 Tripod*
The accessories illustrated or described are not included
as standard delivery.
Display Elements (selection)
a Status bar
b Measurement reference level
c Battery indicator
d Measured-value lines
e Result line
f Measuring functions
g Display tilt angle
h Basic configurations
Assembly
Inserting/Replacing the Batteries
Using alkali-manganese or rechargeable batteries is
recommended for operation of the measuring tool.
With 1.2-V-rechargeable batteries fewer measure-
ments could be possible than with 1.5-V-batteries.
To open the battery lid 9, press the latch 10 and re-
move the battery lid. Insert the batteries/rechargea-
ble batteries. When inserting, pay attention to the
correct polarity according to the representation on
the inside of the battery compartment.
When the empty battery symbol appears on the dis-
play, then approx. 100 measurements are still possi-
ble. When the battery symbol is empty and flashes
red, no further measurements are possible. Change
the batteries or rechargeable batteries.
Always replace all batteries/rechargeable batteries at
the same time. Do not use different brands or types of
batteries/rechargeable batteries together.
Remove the batteries/rechargeable batteries
from the measuring tool when not using it for
longer periods. When storing for longer periods,
the batteries/rechargeable batteries can corrode
and self-discharge.
Operation
Initial Operation
Do not leave the switched-on measuring tool
unattended and switch the measuring tool off
after use. Other persons could be blinded by the
laser beam.
Protect the measuring tool against moisture
and direct sun light.
Do not subject the measuring tool to extreme
temperatures or variations in temperature. As
an example, do not leave it in vehicles for a long
time. In case of large variations in temperature,
allow the measuring tool to adjust to the ambient
temperature before putting it into operation.
