English | 23
Bosch Power Tools 2 609 141 206 | (14.8.14)
Product Features
The numbering of the product features shown refers to the illustration of the measur-
ing tool on the graphic page.
1 Display
2 Measuring button[ ]
3 Minus button[–]
4 Function button[Func]
5 On/Off button[ ]
6 Plus button[+]
7 Battery lid
8 Latch of battery lid
9 Serial number
10 Laser warning label
11 Reception lens
12 Laser beam outlet
13 Laser target plate*
14 Laser viewing glasses*
* The accessories illustrated or described are not included as standard delivery.
Display Elements
a Laser, switched on
b Temperature warning
c Battery low indicator
d Value
e Unit of measure
A) For measurements from the rear measuring tool edge, weak backlighting and 25 °C operating
temperature are applicable for high reflectivity of the target (e. g. a white-painted wall). In addition,
a deviation influence of ± 0.05mm/m must be taken into account.
B) For measurements from the rear measuring tool edge, strong backlighting and – 10 °C to +45 ° C
operating temperature are applicable for low reflectivity of the target (e.g. a black box). In addition,
a deviation influence of ±0.15 mm/m must be taken into account.
C) At 25 °C operating temperature
D) except battery compartment
The measuring tool can be clearly identified with the serial number 9 on the type plate.
