20
#BUUFSZ -J*PO
- Rated voltage 3.6 V
- Capacity 3120 mAh
- Number of battery cells 1
#BUUFSZ$IBSHFS
- Charging time approx. 5.5 h
D)
- Output voltage 5.0 V
- Charging current 1000 mA
- Protection class
/ II
Degree of Protection IP54
(dust and splash water protected)
D)
Bluetooth
®
Bluetooth
®
smart (4.1 low-energy)
F)
Operating frequency band 2402 – 2480 MHz
Max. transmission power 8 mW
.JDSP64#DBCMF 64#
- Charging voltage 5.0 V
- Charging current 1000 mA
A) For measurements from the rear edge of the measuring tool, applies to high
reflectivity of the target (e.g. a white-painted wall), weak backlighting and 25°C
operating temperature. In addition, a deviation of ±0,05mm/m must be taken
into account.
# 'PS NFBTVSFNFOUT GSPN UIF GSPOU FEHF PG UIF NFBTVSJOH UPPM BQQMJFT UP IJHI
reflectivity of the target (e.g. a white-painted wall), and strong backlighting. In
addition, a deviation of ±0.15 mm/m must be taken into account.
C) After user calibration at 0° and 90°,an additional grade error of +/-0.01°/degree to
45° (max.) has to be taken into account.
D) At 25°C operating temperature.
E) In the continuous measurement function, the maximum operating temperature
is +40°C.
F) When using Bluetooth
®
Low Energy tools, it may not be possible to establish a
connection depending on the model and operating system. Bluetooth
®
tools must
support the GATT profile.
G) Automatic switch-off of the measuring tool is adjustable after 2, 5, 10 minutes
or never.
H) The left-hand side of the measuring tool serves as the reference level for grade
measurement.
A long battery runtime is achieved by means of energy-saving measures, such
as deactivating the Bluetooth
®
function when not required, or reducing the display
brightness, etc.
The measuring tool can be clearly identified with the serial number 15 on the type
plate.
