page headingGetting to Know Your Product
(2)
(15)
(9)
(14)
(16)
(8)
(13)
(12)
(1)
(5)
(3)
(4)
(6)
(7)
(10)
(11)
(11)
(11)
1 On/Off Button Switch
2 Dust Bag Assembly
3 Battery Pack
4 Battery Pack Release Tabs
5 Battery Charge Indicator
6 Variable Speed Dial
7 Pivoting Feet
8 Base Mounting Recess
9 Quarter (1/4) Sheet Base Plate
10 Quarter (1/4) Sheet Backing Pad
11 Base Plate Screws (x4)
12 Rectangular (1/3) Sheet Base Plate
13 Rectangular (1/3) Sheet Backing Pad
14 Detail Sheet Base Plate
15 Detail Sheet Backing Pad
16 Gripping Surface (Insulated)
Cordless Orbit Sander
Fig. 1
