Bosch HDS256U - Getting Familiar with Your Range

Page 4
1. Use & Care Manual
2. Installation Instructions
3. AHAM Anti-Tip Brochure
4. Bosch Cookbook
5. Probe
6. Telescopic Rack
7. Anti-Tip Bracket
8. Screws for Anti-Tip Bracket
9. Registration Card
10. Incandescent Lights (not visible)
11. Oven Control
12. Panel and Knob
13. Broil Element (not visible)
14. Convection Fan and Element (not visible)
15. Probe Receptacle
16. Rack Positions
17. Oven Gasket
18. Model & Serial # Plate
19. Bake Element (not visible)
20. Door Lock (not visible)
21. Oven Rack Back
22. Oven Rack Front
23. Broiler Pan
24. Warming Drawer
25. Warming Drawer Rack
26. Burner Grates (2)
27. Burner Caps (4)
28. Oven Vent
Getting Familiar with Your Range
OVEN RACK
TELESCOPIC
RACK
PROBE
WARMING
DRAWER
RACK
BROIL PAN
Parts Included with Your Dual Fuel Range:
Actual parts are larger than depicted in above graphics.
ANTI-TIP
BRACKETS
AND SCREWS
11
12
16
15
5
23
18
21
22
24
25 6
7 & 8
28
