Know your Indego
All these items are contained
in the carton box:
Tools required (not included):
► Mallet (to secure the pegs)
► Wire strippers (to cut and strip the wire)
Docking station
1 Screw holes
2 House symbol pointing
outside of cutting area
3 Tree symbol, pointing inside
of cutting area
4 Cable duct
5 Charging pins
6 Docking station status indicator
7 Rating label
8 Perimeter wire connector point red
9 Perimeter wire connector point black
10 Charging socket
Top of Indego
1 Stop button
2 Display
3 Mower ‘On’ indicator
4 Height of cut button
5 Height of cut – release button
6 QR code B (connected Indego)
7 Bumper
Back of Indego
1 On/Off switch
2 Anti-theft sticker
3 Rating label
4 Data connection port
5 Handle
Bottom of Indego
1 Cutter blades
2 Caster wheels
3 Drive wheels
4 Charging contacts (pins)
1 Indego
2 Docking station
3 Docking station cover
4 Power supply unit
5 Perimeter wire
6 Pegs (to keep the perimeter
wire in place)
7 Wire connector
8 Screws and hex key
(for docking station)
9 Two rulers (30 cm and 75 cm)
10 Instruction manual and
installation guide
