26 | Troubleshooting LM Series Heat Pump
LM Series Heat Pump8 733 905 315 (2013/9) Subject to change without prior notice
Compressor Ohms
Model Voltage Start Winding Line-to-Line Run Winding
LM024
-1
1.64 1.30
-2
2.17 1.48
-3
2.153 2.153 1.763
-4
8.60 8.60 7.30
LM036
-1
1.52 0.88
-2
1.15 1.22
-3
1.53 1.53 1.21
-4
5.87 5.87 4.86
LM048
-1
1.86 0.52
-2
0.88 0.70
-3
1.03 1.03 0
-4
4.17 4.17 0
LM060
-1
1.63 0.39
-2
0.87 0.52
-3
0.68 0.68 0
-4
3.20 3.2 0
LM070
-1
1.85 0.34
-3
0.60 0.60 0
-4
2.52 2.52 0
Tolerance +/- 7%. All resistance values must be measured with compressor at room temperature.
