Airflow Tables | 37LM Series Heat Pump
8 733 905 315 (2013/9)Revised 09-13
Figure 24: Water side pressure drop in PSIG
Series GPM
Water PD @ 77°EWT
with Water
LM024
3 0.7
41.2
5 1.7
62.4
7 3.2
84.0
LM036
4.5 1.3
62.2
7.5 3.2
94.5
10.5 5.9
12 7.5
LM048
6 1.1
81.8
10 2.7
12 3.7
14 4.9
16 6.2
LM060
7.5 1.1
10 1.9
12.5 2.8
15 3.9
17.5 5.2
20 6.6
LM070
9 0.9
12 1.4
15 2.1
18 3.0
21 3.9
24 5.0
