Preparation
-4-
DIGITAL MULTI-DETECTOR DMD4
Article number 3 601 K10 010
Maximum scanning depth*:
Ferrous metals 4" / 100 mm
Non-ferrous metals (copper) 3-1/8" / 80 mm
Copper wiring (live) 2" / 50 mm
Wood Substructures (studs) 3/4" / 20 mm
Automatic switch-off After approx. 5 min
Operating temperature 14 °F 122 °F
–10 °C +50 °C
Storage temperature – 4 °F –158 °F
–20 °C +70 °C
Battery 1 x 9 V 6LR61
Rechargeable battery 1 x 9 V 6F22
Operating lifetime (alkali-manganese batteries) Approx. 6 h
Weight according to EPTA-Procedure 01/2003 0.53 lbs/ 0.24 kg
* Depends on material and size of objects as well as material and condition of structure.
** Less scanning depth for wires/conductors that are not “live”.
Please observe the article number on the type plate of your multi-detector.
Technical Data
INSERTING/REPLACING THE BATTERY
Use only alkali-manganese or rechargeable
batteries.
To open the battery lid
10, press the latch 12
in the direction of the arrow and fold up the
battery lid. Insert the supplied battery. Pay
attention that the polarity is correct, according
to the + and - symbols on the inside of the
battery lid.
• When the battery indication
k in the display
lights up, measuring is possible for approx. 1
h when using alkali-manganese batteries
(service life is shorter with rechargeable
batteries).
• When the battery indication
k flashes,
measuring is still possible for approx. 10
minutes.
• When the battery indication k and the
illuminated ring
1 (red) are flashing,
measuring is no longer possible and the
battery or the rechargeable battery
respectively, must be replaced.
•
If the multi-detector is not used for a long
period of time, the battery must be
removed.
The battery can corrode or
discharge itself over long periods.
BM 2609140574 08-08 9/3/08 8:40 AM Page 4
