Focus Automatic with manual override
Iris Automatic with manual override
Field of View 2.7° to 48°
Video Output 1.0 Vp-p, 75 Ohm
Gain Control Off/Auto (with adjustable limit)
Synchronization Line-Lock (–120° to 120° vertical phase
adjust) or internal crystal
Aperture Correction Horizontal and vertical
Horizontal Resolution NTSC: 470 TVL, typical
PAL: 480 TVL, typical
Sensitivity (typical) 30 IRE 50 IRE
F1.4, 1/60 (1/50)
shutter, max AGC
0.5 lx 0.8 lx
Electronic Shutter Speed
(AES)
1 to 1/10,000
SNR >50 dB
White Balance 2000 K to 10,000 K
Mechanical/Electrical
Model In-Ceiling Indoor
Pendant
EnviroDome®
Weight 2.66 kg
(5.86 lb)
2.88 kg
(6.3 lb)
3.32 kg
(7.3 lb)
Pan Range 360° cont. 360° cont. 360° cont.
Tilt Angle 1° above
horizon
18° above
horizon
18° above
horizon
Variable
Speed
0.1°/s-120°/s 0.1°/s-120°/s 0.1°/s-120°/s
Pre-position
Speed
Pan: 360°/s
Tilt: 100°/s
Pan: 360°/s
Tilt: 100°/s
Pan: 360°/s
Tilt: 100°/s
Preset
Accuracy
± 0.1° typ. ± 0.1° typ. ± 0.1° typ.
Power 21-30 VAC
50/60 Hz
21-30 VAC
50/60 Hz
21-30 VAC
50/60 Hz
Power Draw: (typ)
Analog
Models
10 W 10 W 46 W
6
Ethernet
Models
14 W 14 W 50 W
6
6 Add 16 W if using VG4-SHTR-XT kit.
Surge Suppression
Protection on
Video
Peak current 10 kA (Gas Tube Arrester), peak
power 1000 W (10/1000 μ)
Protection on
RS-232/485,
Biphase
Peak current 10 A, peak power 300 W (8/20 μ)
Protection on
Alarm Inputs
Peak current 17 A, peak power 300 W (8/20 μ)
Protection on
Alarm Outputs
Peak current 2 A, peak power 300 W (8/20 μ)
Protection on
Relay Outputs
Peak current 7.3 A, peak power 600 W
(10/1000 μ)
Protection on
Power Input
(Dome)
Peak current 7.3 A, peak power 600 W
(10/1000 μ)
Protection on
Power Output
(Arm Power
Supply)
Peak current 21.4 A, peak power 1500 W
(10/1000 μ)
Environmental
Model In-Ceiling Indoor
Pendant
EnviroDome®
Design
Rating
Plenum Rated IP66 IP66
Operatin
g
Temp.
–10°C to 50°C
(14°F to
122°F)
–10°C to 50°C
(14°F to
122°F)
–40°C to 50°C
(–40°F to 122°F)
Storage
Temp.
–40°C to 60°C
(–40°F to
140°F)
–40°C to 60°C
(–40°F to
140°F)
–40°C to 60°C
(–40°F to 140°F)
Humidity 0% to 90%
relative, non-
condensing
0% to 90%
relative, non-
condensing
0% to 100%
relative,
condensing
Miscellaneous
Sectors/Titling 16 independent sectors with 20-character titles/
sector
Camera Setup/
Control
Biphase, RS-232, RS-485, Bilinx
7
(coax)
Communication
s Protocols
Biphase, Bilinx
7
, Pelco P, and Pelco D
Pre-positions 64, each with 20-character titles
Preset Tour One (1), consisting of up to 64 scenes,
consecutively
Supported
Languages
Czech, Dutch, English, French, German, Italian,
Polish, Portuguese, Russian and Spanish
7 Bilinx not available on Ethernet models.
User Connections
Power (Camera) 21-30 VAC, 50/60 Hz
Power (Heater) 21-30 VAC, 50/60 Hz
Biphase ± Control Data
Audio Line In
8
9 K Ohm typ, 5.5 Vp-p max
4 | AutoDome 200 Series PTZ Camera System
