English | 5
Bosch Power Tools 1 619 PA1 892 | (8.3.11)
Safety Warnings for Sabre Saws
f Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord. Cutting ac-
cessory contacting a “live” wire may make exposed metal
parts of the power tool “live” and could give the operator an
electric shock.
f Keep hands away from the sawing range. Do not reach
under the workpiece. Contact with the saw blade can lead
to injuries.
f Apply the machine to the workpiece only when
switched on. Otherwise there is danger of kickback when
the cutting tool jams in the workpiece.
f When sawing, the adjustable footplate 2 must always
faces against the workpiece. The saw blade can become
wedged and lead to loss of control over the machine.
f When the cut is completed, switch off the machine and
then pull the saw blade out of the cut only after it has
come to a standstill. In this manner you can avoid kick-
back and can place down the machine securely.
f Use only sharp, flawless saw blades. Bent or unsharp
saw blades can break or cause kickback.
f Do not brake the saw blade to a stop by applying side
pressure after switching off. The saw blade can be dam-
aged, break or cause kickback.
f Clamp material well. Do not support the workpiece
with your hand or foot. Do not touch objects or the floor
with the the saw running. Danger of kickback.
f Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility company
for assistance. Contact with electric lines can lead to fire
and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.
f When working with the machine, always hold it firmly
with both hands and provide for a secure stance. The
power tool is guided more secure with both hands.
f Secure the workpiece. A workpiece clamped with clamp-
ing devices or in a vice is held more secure than by hand.
f Always wait until the machine has come to a complete
stop before placing it down. The tool insert can jam and
lead to loss of control over the power tool.
Products sold in GB only: Your product is fitted with a
BS 1363/A approved electric plug with internal fuse (ASTA
approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an author-
ised customer service agent. The replacement plug should
have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains sock-
et elsewhere.
Products sold in AUS and NZ only: Use a residual current de-
vice (RCD) with a rated residual current of 30 mA or less.
Product Description and Specifications
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Intended Use
The machine is intended for sawing wood, plastic, metal and
building materials while resting firmly on the workpiece. It is
suitable for straight and curved cuts. When using the appro-
priate bimetal saw blades, it is possible to cut flush to the
workpiece surface. The saw blade recommendations must be
observed.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Saw blade*
2 Adjustable footplate
3 Saw blade holder
4 SDS clamping lever for saw blade release
5 Stroke rod
6 Rotary switch for orbital action
7 On/Off switch
8 Stand-by indicator
9 Handle (insulated gripping surface)
10 Clamping plate
11 Screws for footplate adjustment
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Sabre saw PSA 1150
Article number
3 603 CA8 0..
Rated power input
W 1150
Stroke rate at no load n
0
min
-1
0 – 2700
Tool holder
SDS
Stroke rate control
z
Stroke
mm 29
Cutting capacity, max.
– in wood
– in non-alloy steel
– Pipe diameter
mm
mm
mm
200
30
80
Weight according to
EPTA-Procedure 01/2003
kg 4.5
Protection class
/II
The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine.
The trade names of the individual machines may vary.
