English | 25
Bosch Power Tools 1 609 929 S69 | (20.4.09)
Intended Use
The machine is intended for cutting, roughing,
and brushing metal and stone materials without
using water.
For cutting metal, a special protection guard for
cutting (accessory) must be used.
For cutting stone, a special extraction hood for
cutting with cutting guide (accessory) must be
used.
With approved sanding tools, the machine can
be used for sanding with sanding discs.
Product Features
The numbering of the product features refers to
the illustration of the machine on the graphics
page.
1 Spindle lock button
2 On/Off switch
3 Auxiliary handle
4 Grinder spindle
5 Protection guard for grinding
6 Locking screw for protection guard
7 Protection guard for cutting*
8 Mounting flange with O-ring
9 Grinding/cutting disc*
10 Clamping nut
11 Quick-clamping nut *
12 Protection guard for für grinding cup*
13 Grinding cup*
14 Hand guard*
15 Spacer discs*
16 Rubber sanding plate*
17 Sanding sheet*
18 Round nut*
19 Cup brush*
20 Cutting guide with dust extraction protec-
tion guard *
21 Diamond cutting disc*
*Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
Technical Data
Angle Grinder PWS 20-230 PWS 20-230 J PWS 1900
Article number
3 603 C59 W.. 3 603 C59 V.. 3 603 C59 W..
Rated power input
W20002000 1900
Output power
W12501250 1170
Rated speed
min
-1
6500 6500 6500
Grinding disc diameter, max.
mm 230 230 230
Thread of grinder spindle
M 14 M 14 M 14
Thread length (max.) of grinder spindle
mm 25 25 25
Reduced starting current
– z –
Weight according to EPTA-Procedure
01/2003
kg 4.4 4.4 4.4
Protection class
/II /II /II
The values given are valid for nominal voltages [U] of 230/240 V. For lower voltage and models for specific countries,
these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines
may vary.
Only for power tools without reduced starting current: Starting cycles generate brief voltage drops. Interference with
other equipment/machines may occur in case of unfavourable mains system conditions. Malfunctions are not to be
expected for system impedances below 0.25 ohm.
