Bosch PXY875KW1E User Manual

en Hood connection
48
About data protection
When your appliance is connected for the first time to a
WLAN network, which is connected to the Internet, your
appliance transmits the following categories of data to
the Home Connect server (initial registration):
■ Unique appliance identification (consisting of
appliance codes as well as the MAC address of the
installed WiFi communication module).
■ Security certificate of the WiFi communication
module (to ensure a secure IT connection).
■ The current software and hardware version of your
domestic appliance.
■ Status of any previous resetting to factory settings.
This initial registration prepares the Home Connect
functions for use and is only required when you want to
use these Home Connect functions for the first time.
Note:
Ensure that the Home Connect functions can be used
only in conjunction with the Home Connect app.
Information on data protection can be accessed in the
Home Connect app.
Declaration of Conformity
Robert Bosch Hausgeräte GmbH hereby declares that
the appliance which features Home Connect is in
accordance with the basic requirements and the other
relevant provisions of the directive 2014/53/EU.
A detailed RED Declaration of Conformity can be found
online at www.bosch-home.com/de on the product
page for appliance in the additional documents.
2.4 GHz band: max. 100 mW
5 GHz band: max. 100 mW
eHood connection
Ho o d c onnect i on
You can connect this appliance to a suitable extractor
hood and then control the functions of the hood via your
hob.
You have various options for connecting the appliances
together:
Home Connect
Two appliances can be connected using the Home
Connect app provided that both of them are Home
Connect-compatible.
Both appliances can be controlled via the app and via
the control panel.
Refer to the Home Connect documents supplied and
the Home Connect section for more information.
~ "Home Connect" on page 43
Connecting appliances directly
If the appliance is connected directly to an extractor
hood, the extractor hood can be controlled via the hob.
It is then not possible for either of the appliances to
connect to your home network or to the app. Both
appliances can be controlled via the control panel.
y
BE BG CZ DK DE EE IE EL
ES FR HR IT CY LV LT LU
HU MT NL AT PL PT RO SI
SK FI SE UK NO CH TR
5 GHz Wi-Fi: for indoor use only

Bosch PXY875KW1E Specifications

General

Timer type	Digital
Control type	Touch
Display type	TFT
Built-in display	Yes
Control position	Top front
Certification	AENOR, CE
Number of power levels	17
Hob type	Zone induction hob
Frame color	Aluminum
Product color	Black
Top surface type	Glass-ceramic
Appliance placement	Built-in
Cooking zone 1 type	Large
Cooking zone 1 boost	3700 W
Cooking zone 1 power	2200 W
Cooking zone 1 shape	Rectangular
Cooking zone 1 position	Left rear
Cooking zone 2 position	Left front
Cooking zone 3 position	Right rear
Cooking zone 4 position	Right front
Number of cooking zones	4 zone(s)
Flexible cooking zone type	Bosch FlexPlus Zone
Cooking zone 1 power source	Electric
Number of gas cooking zones	0 zone(s)
Boost flexible cooking zone 1	3300 \\ 3700 W
Number of flexible cooking zones	2 zone(s)
Number of simultaneously used cooking zones	4
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Connected load (gas)	0 W
Connected load (electric)	7400 W
Package depth	953 mm
Package width	603 mm
Package height	126 mm
Package weight	19000 g

Weight and Dimensions

Depth	527 mm
Width	816 mm
Height	51 mm
Weight	17000 g
Cord length	1.1 m
Installation compartment width	780 mm
Installation compartment depth (max)	500 mm
Installation compartment depth (min)	490 mm
