CLIMATE 5000 RAC SINGLE SPLIT (R32) – 6720894076 (2019/08) 7
Specifications
2.2.2 Outdoor Unit
Abbreviation
Paraphrase
4-WAY 4-WAY VALVE
AC-FAN
Alternating Current FAN
DC-FAN
Direct Current FAN
CT1
AC Current Detector
COMP
Compressor
L-PRO
Low Pressure Switch
H-PRO
High Pressure Switch
EEV
Electronic Expansion Valve
Table 3.
Outdoor Units 2,6-2 / 3,5-2 / 5,3-2 OUE
OPTIONAL
OPTIONAL
Y/G
Y/G
Y/G
Y/G
Y/G
Y/G
OPTIONAL AC-FAN
OPTIONAL
DC-FAN
AC-FAN
DC-FAN
COMPRESSOR
CAPACITOR
4-WAY
CN 7
S
W
2(N)
L
N
1(L)
U
V
W
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
TEST PORT
OPTIONAL
OPTIONAL
Note: --------------
This symbol indicates the
element is optional,the actual
shape shall be prevail.
REACTOR
ELECTRONIC
EXPANSION
VALVE
DISCHARGE TEMP. SENSOR
CONDENSER TEMP. SENSOR
AMBIENT TEMP. SENSOR
WHITE
CRANKCASE
HEATER
PAN
HEATER
BLUE
BROWN
MAIN
BOARD
BLUE
BLUE
BLUE
RED
RED
RED
RED
YELLOW OR BLACK
BLUE OR BLACK
BLACK
BLACK
BLUE OR WHITE
BLUE OR
WHITE
WHITE
INDOOR UNIT
POWER SUPPLY
Fig. 2.

Bosch R32 Specifications
