Miscellaneous Fasteners (cont.)
(43) B3 x 5/8”
Washer-Head Screw
(for Insert Plate)
(47) 1/4-20 x 2¼" Square-Head Bolt
(for Fence Base)
(41) #10-32 x 7/8"
Countersunk-Head Screw
(for Miter Channel)
(44) #10-32 x 2½" Truss-Head Screw
(for Fence Retaining Brackets)
(45) 1/4-20 x 1¼" Carriage Bolt
(for Faceplate)
Parts List
(48) 1/4-20 x 2½" Carriage Bolt
(for Overhead Guard)
(50) Lower Slide Plate
(for Tabletop Featherboard Mounting)
(49) Upper Slide Plate
(40) #10-32 x 5/8"
Truss-Head Screw
(for Switch Box)
(38) #10-32 x 3/8"
Truss-Head Screw
(for Guide Pin Guard)
(39) #10-32 x 1/2″
Pan-Head Machine
Screw (for Router)
(42) 5/16-18
x
1/2
″
Pan-Head Machine
Screw (for Router)
(46) 1/4-20 x 1½" Carriage Bolt
(for Featherboards)
To Next Page
