Parts List
Key No. Description Quantity
A ROUTER TABLE ASSEMBLY COMPONENTS
(shipped preassembled)
1
Router Tabletop, 1"
1
2 Insert Plate 1
3 Miter Channel (includes 3 #10-32 x 7/8" screws, item 41) 1
4
1
5 Router Release Mechanism (not shown) 1
6 Front Table Housing 1
7 Rear Table Housing 1
8 Left Folding Steel Legs 2
9 Tool Box w/ Hinged Cover 2
10 Right Folding Steel Legs 2
11 Insert Ring Set (3 rings per set) 1
11A Insert Ring w/ 1¼" dia. hole 1
11B Insert Ring w/ 1
7
⁄
8
" dia. hole 1
11C Insert Ring w/ 2
1
⁄
8
" dia. hole 1
12 Fence Retaining Bracket (not shown) 2
13 Small Star Clamping Knob (not shown) 2
B SWITCH BOX ASSEMBLY COMPONENTS
14 Switch Box Assembly (with lockout key) 1
15 Lockout Key 1
C FENCE ASSEMBLY COMPONENTS
(shipped preassembled)
16 Router Table Fence 1
17
Featherboard Mounting Rail
1
18
Overhead Guard Assembly (includes spacer)
1
19 Faceplate 2
20 Outfeed Shim Plate (may be attached to outfeed side of fence) 2
21 Clamping Knob 11
22 Featherboard 2
– Spacer (see item 31) 2
D MITER GAUGE ASSEMBLY COMPONENTS
23 Miter Bar 1
24 Protractor Head 1
– Flat Washer (see item 33) 1
25 Small Clamping Knob 1
E STARTER PIN COMPONENTS
26 Starter Pin 1
27 Starter Pin Guard 1
– Guard Screw (see item 38) 1
F BIT HEIGHT GAUGE ASSEMBLY (shipped preassembled)
28 Gauge Body 1
29 Gauge Pointer 1
•
If ANY of the parts are
missing, DO NOT attempt
to assemble, install, or use your router table
until the missing parts have been found or
replaced and your router table has been
properly and correctly assembled per this
manual.
(877-267-2499).
•
In order to simplify handling and to minimize
any damage that may occur during shipping,
your router table comes mostly assembled.
Repositioning of some parts will be required.
•
Separate all parts from the packaging
materials and check each part against the
illustrations and the parts lists to make sure
that all parts have been included. Do this
before discarding any of the packaging
material.
Refer to Parts List below and on pages 8–10.
