About this documentation | Control panels CP1 and CP2 | 5/24
Safety instructions are set out as follows:
SIGNAL WORD
Type and source of danger!
Consequences of noncompliance
▶ Danger prevention measures
• Warning sign: draws attention to the danger
• Signal word: identifies the degree of the danger
• Type and source of danger: indicates the type and source of the danger
• Consequences: describes the consequences of non-compliance
• Precautions: states how the danger can be avoided
Table 2: Hazard classes as defined in ANSI Z535�6
Warning sign, signal word Meaning
DANGER
Identifies adangerous situation that will result in death or
serious injury if it is not avoided.
WARNING
Identifies adangerous situation that may result in death or
serious injury if it is not avoided.
CAUTION
Identifies adangerous situation that may result in minor to
moderate injury if it is not avoided.
NOTICE
Property damage: The product or surrounding area may be
damaged.
1�3�2 Symbols
The following symbols indicate notices that are not safety-relevant but increase
understanding of the documentation.
Table 3: Meaning of symbols
Symbol Meaning
If this information is disregarded, the product cannot be used and/or
operated to its full extent.
▶
Single, independent action
1.
2.
3.
Numbered instruction:
The numbers indicate that the actions must be completed in order.
1�3�3 Designations
This documentation uses the following designations:
Table 4: Designations
Designation Meaning
CP1 Control panel CP1 for Electrohydraulic Hitch Control EHC
CP2 Control panel CP2 for Electrohydraulic Hitch Control EHC
The designations "product" or "control panel" are used as the generic term for the
"control panels CP1 and CP2".
