1 System Presentation
1.1 Brief Description of the VDP 08.3/40.3 Operator Terminals
The VDP 08.3/40.3 operator terminals are passive operator and visualization
terminals. They form a PC based operator terminal when used with a control
cabinet PC equipped with a CDI interface. Currently, the VSB 40.3 and the
VPB 40.3 devices are available as control cabinet PCs. The VDP 08.3/40.3
operator terminals can be attached to a bracket with a VESA adapter, whereas
the control cabinet PC can be installed e.g. into a control cabinet. The data
transmission between control cabinet PC and a VDP 08.3/40.3 operator termi‐
nal is carried out via the CDI interface. VDP 08.3/40.3 devices consist of a
robust and single metal housing.
Y-Repeater
A Y-repeater is an accessory to connect VDP devices to a control cabinet PC
(see chapter 1.3 "Accessories" on page 7). The Y-repeater can be used to
connect two VDP devices to a control cabinet PC.
The Y-repeater is described in chapter 10 "Y-Repeater" on page 59.
1.2 Variants
1.2.1 Characteristic Features
The operator terminals are available in different variants, see type designation
code in chapter 12 "Ordering Information" on page 71. They differ in the
display size.
VDP 08.3 DP
Display 213.36 mm TFT (8.4")
Touch screen Yes
3 × keys
1 x emergency stop button
Yes
Fig.1-1: Features VDP 08.3 device
VDP 40.3 DI
Display 381 mm TFT (15")
Touch screen Yes
3 × keys
1 x emergency stop button
Yes
Fig.1-2: Features VDP 40.3 device
1.2.2 Displays with Touch Screen and Keys
The front panel with touch screen also consists of a 5 mm thick aluminum panel
with beveled edges. The front panel is integrated. The application software is
operated via the touch-sensitive interface of the display.
Danger of destruction of the touch screen if
operated with inappropriate objects (e.g.
screwdriver).
NOTICE
Operate the touch screen only with your finger or with a touch pen.
DOK-SUPPL*-VDP*08.3***-PR02-EN-P
Rexroth IndraControl VDP 08.3/40.3 Operator Terminal
Bosch Rexroth AG 5/81
System Presentation

Bosch Rexroth IndraControl VDP 08.3 Specifications

General

Touchscreen	Resistive
Display Type	TFT LCD
Brightness	400 cd/m²
Contrast Ratio	600:1
Operating Temperature	0°C to 50°C
Power Supply	24V DC
Weight	1.5 kg
Display Size	8.4 inches
Display Resolution	800 x 600 pixels
Protection Class	IP65
Storage Temperature	-20°C to 60°C
Power Consumption	15 W (typical)
