Bosch RH745 - Functional Description and Specifications; Rotary Hammer

-7-
Model number RH745 RH850VC
Shank style SDS-Max® SDS-Max®
&=.2:2&5&(.9.*8
Carbide tipped bits 1-3/4" 1-7/8"
Carbide tipped core bits 5" 6"
:3(9.43&1*8(7.59.43&3)5*(.+.(&9.438
.8(433*(9 9-* 51:, +742 9-* 54<*7 84:7(* '*+47* 2&0.3, &3>
&88*2'1>&)/:892*39847 (-&3,.3, &((*8847.*8 Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
49&7>&22*7
 For tool specifications refer to the nameplate on your tool.
FIG. 1
LOCKING SLEEVE
DUST SHIELD
VENTILATION OPENINGS
AUXILIARY
HANDLE
HAND GRIP
VARIABLE
SPEED DIAL
SERVICE
REMINDER
LIGHT
SELECTOR LEVER
TRIGGER
RELEASE
SWITCH
TRIGGER
SWITCH
VIBRATION DAMPER
HANDLE / HAMMER MECHANISM
(RH850VC ONLY)
BM 160992A0H1 01-14_RH745 RH850VC 1/22/14 10:22 AM Page 7
