1.5 m/s2.
The vibration level and noise emission value given in these instructions have been measured in accordance with a
standardized measuring procedure and may be used to compare power tools. They may also be used for a
preliminary estimation of vibration and noise emissions.
The stated vibration level and noise emission value represent the main applications of the power tool. However, if the
power tool is used for other applications, with different application tools or is poorly maintained, the vibration level
and noise emission value may differ. This may significantly increase the vibration and noise emissions over the total
working period.
To estimate vibration and noise emissions accurately, the times when the tool is switched off or when it is running but
not actually being used should also be taken into account.
This may significantly reduce vibration and noise emissions over the total working period.
Implement additional safety measures to protect the operator from the effects of vibration, such as servicing the
power tool and application tools, keeping their hands warm, and organizing workflows correctly.
Assembly
Pull the plug out of the socket before carrying out any work on the power tool.
Changing the abrasive tools
You can use the SDS mount (12) on the grinding spindle (1) to easily and conveniently change the abrasive tool
without using additional tools.
The Autolock system locks the grinding spindle when the power tool is switched off. It is better to attach or remove
abrasive tools when the grinding spindle is fixed in place.
Flexible rollers (8), flap wheels (9) and wire brushes can be attached directly to the grinding spindle (1).
For sanding sleeves (11), the shank (10) must first be attached to the grinding spindle (1). The sanding sleeve (11)
can then be twisted onto the shank (10).
Fitting the abrasive tools (see figure A)
Hold the abrasive tool so that the SDS mounting springs (13) are pointing away from the grinding spindle (1).
Slide the abrasive tool onto the grinding spindle (1) in a turning motion until you hear it engage.
Check that it is locked by pulling on the abrasive tool.
Fitting the sanding sleeves (see figure B1 − B2)
Hold the shank (10) so that the SDS mounting springs (13) are pointing away from the grinding spindle (1).
Slide the shank (10) onto the grinding spindle (1) in a turning motion until you hear it engage.
Check that it is locked by pulling on the shank.
Wind the sanding sleeve (11) over the shank (10) until the rubber flaps are completely covered.
Removing the abrasive tool (see figures C1−C2)
Press the SDS actuator button (14) to unlock it and pull the abrasive tool off the grinding spindle (1).
Dust extraction guard
Note: When working with wire brushes, always use the dust extraction guard provided.
Fitting the dust extraction guard (see figure D)
Push the dust extraction guard (2) all the way into the two fastening grooves (16) of the tool arm (15); note that
