Bosch Tronic 4000 Series - Air Purging Steps; Appliance Configuration Overview; Setting the Power Level

Installation (only for approved contractors)
19
Tronic 4000 – 6721830066 (2021/06)
▶ Turn on a hot water tap for 1 minute to purge air from the
appliance.
Fig. 31
[1] Hot water tap
5.9 Appliance configuration
CAUTION
Risk of electric shock!
Before configuring the appliance,
▶ Turn off the electric supply at the electrical cabinet.
It is possible to configure several parameters on the same
appliance.
▶ Use the electronic Jumpers provided to carry out the
different appliance configurations.
Fig. 32 Supplied electronic Jumpers
▶ Save the removed Jumpers for future changes or
installations.
Fig. 33
5.9.1 Configure the power level
▶ Use jumpers J2 and J3 to configure the power level of the
appliance, according to the table below.
