12 | VLS 5235 | Operationen
5.15 Technical data
Items Parameter
Rated load capacity 3500KG
Length of platform 4300mm
Width of vehicle 1600-2100mm
Wheel base 2100-3200mm
Full rise height 1850mm
Full lowered height 330mm
Full rise time with load ≤50s
Full lowered time with load ≤30s
Max working hydraulic pressure 24MPa
Min working hydraulic pressure 22MPa
Max working pneumatic pressure 8kg/cm²
Min working pneumatic pressure 6kg/cm²
Load capacity of secondary lift 3.5ton
Lifting height of secondary lift 450mm
Oil Volume 18L
Tab. 1: VLS 5235
Items Parameter
Capacity 2.2KW
Voltage 380V
Phase 3P
Current 4.6A
Frequency 50HZ
Rotation speed 2880r/m
IP 44
Tab. 2: Motor
Items Parameter
Max working pressure 35MPa
Min bending diameter 100mm
Burst pressure 140Mpa
Tab. 3: Oil hose
6. Operation
6.1 Essential points for operation
¶ Only authorized, trained personnel aged 18 years or
older are permitted to operate the lifting platform.
¶ Only passenger cars or motor vehicles with a
maximum overall weight of 3500kg may be lifted.
¶ In the case of maximum load, the front/rear load
distribution must not exceed 2 : 1.
¶ Only vehicles with a wheelbase permitting full
contact between the tyres and runways may be
lifted.
¶ The lifting platform must only be operated via the
supplied operating unit.
¶ Before moving the lifting platform, make sure that
there are no persons within the danger zone, and
that no objects are leaning against or positioned on
the vehicle or lifting platform.
¶ No unauthorized personnel must be allowed in the
vicinity of the lifting platform.
¶ Riding on the lifting platform or in the raised vehicle
is prohibited.
¶ Do not use the lifting platform as a crane or a
support for other lifting mechanisms (e.g. pulley).
¶ Electric welding work on the raised vehicle or on the
lifting platform itself is only permitted if the master
switch is turned to OFF (O).
¶ Never use the lifting platform in the event of
malfunction or component damage.
¶ If the lifting platform malfunctions, shut it down
immediately, secure it against unauthorized use,
and notify Bosch customer service or an authorized
service outlet.
¶ Lock the master switch when not in use.
Please also note the following when using the auxil-
iary lift:
¶ Only passenger cars or motor vehicles with a
maximum overall weight of 3500 kg may be lifted.
¶ In the case of maximum load, the front/rear load
distribution must not exceed 3 : 2.
¶ Lift vehicles only by the four lifting points specified
by the vehicle manufacturer.
¶ Certain special-purpose vehicles must not be lifted
using a auxiliary lift. Before lifting any vehicle, you
must establish whether it is such a special-purpose
vehicle.
