Bosch WAN282A2 - Connecting the Device

Set up and connect de
4.5 Connect the device
3. Carefully open the tap and check
whether the connection points are
tight.
Connect the water inlet hose Notes
Connection types water drain
¡ Note the information
on the subject of security → page 4
and avoid property damage
→ Page 11, to keep your device safe
need to be able to.
¡ Make sure you do that
Connect the device to a water inlet
with a safety device against
drinking water contamination
through backflow (according to DIN
EN 1717). The connection valves /
water taps provided for this are
equipped with this safety device if
the building is properly installed.
The information will help you to
connect this device to the water drain.
Note: Note the information on
security
→ page 4 and avoid damage to property.
the → Page 11, to use your device
safely.
CAUTION!
When pumping out, the water
drainage hose is under pressure and
can come loose from the installed
connection point.
▶ The water drain hose against
Secure unintentional loosening.
1. Connect the water inlet hose to the
device.
Note: Note the pumping heights.
The pumping heights are: minimum:
60 cm, maximum: 100 cm
2
The connecting
pose with a
Hose clamp
(24-40 mm) si-
to cherish.
1
2. Connect the water inlet hose to the
tap (26.4 mm = 3/4 ").
Expiration in a
sink
The water drainage
running hose with
a bend
→ Page 33 fixation
ren and secure.
¾˝
min.
10mm
Expiration in a
Plastic pipe
The water drainage
running hose with
min.
17mm
with rubber sleeve. a bend
→ Page 33 fixation
ren and secure.
17th
