20 | WBE 4100 | How to use the machine and surfing menuen
3.2 Configuration of the board
Press “SET” until the notice “TOL” is shown and then
press "MM/INCH“.
Left Display
Right Display
Description
POT OFF/ON It turns on and off the in-
ternal automatic gauge
3.3 Self-calibration
Press “SET” until the notice “CAL” is shown and then
press “MM/INCH“.
Left Display
Right Display
Description
C-1 Memorization of the flange
zero group and shaft
Left Display
Right Display
Description
D-1 0 or higher Calibration of the distance
potentiometer: position of rest
Left Display
Right Display
Description
D-2 200 Calibration of the distance
potentiometer: position at 20cm
Left Display
Right Display
Description
H-1 ex.: 14“ Calibration of the diam-
eter potentiometer
Left Display
Right Display
Description
C-2 Setting up of the wheel size and
memorization of the unbalance
C-3 Setting up of the calibration weight
and launch with the weight inside
C-4 Launch with the weight outside
C-5 Adjustment of the angle
3.4 Auto-diagnosis
Press “SET” until the notice “TST” is shown and then
“MM/INCH“.
Left Display
Right Display
Description
Msr Press "+“ DISTANCE to
roll down menu
ex.: 384 1° shown value:
measured tension left pick-up
Ex.: 603 2° shown value: meas-
ured tension right pick-up
ex.: 179 Ex.: 580 3° shown value: phase an-
gle difference
Ex.: 2 4° value: Ratio between the
rounded off pick-ups
Left Display
Right Display
Description
Enc It shows the position of the
encoder from 0 to 255
Left Display
Right Display
Description
SP Speed in turn/min of the shaft
Left Display
Right Display
Description
A0 510 Reading analog en-
try of the right pick-up
Press "+“ DISTANCE to
roll down the menu
A1 510 Reading analog en-
try of the left pick-up
A2 510 Reading analog entry of the
enlarged right pick-up
A3 510 Reading analog entry of the
enlarged left pick-up
A4 ### NON USED
A5 200 Reading distance potentiometer
A6 ### NON USED
A7 200 Reading diameter potentiometer
Left Display
Right Display
Description
INP ON/OFF Position of the carter: OFF open,
ON lowered
Left Display
Right Display
Description
Cnt Press "+“ DISTANCE to
roll down the menu
1 500 Overall launches ex:1500
6 Daily launches, since when the bal-
ancing machine has been turned on
Left Display
Right Display
Description
Led Press "+“ DISTANCE to
roll down the menu
Left Display
Right Display
Description
Tar Press "+“ DISTANCE to
roll down the menu
Left Display
Right Display
Description
Rel off Start of the respective bal-
ancing procedure
! NOTE: All the options are described in details on the
following pages.
