Disassembly
Disassembly
–
–
Drum, Outer Drum (Tub) & Dampers (2)
Drum, Outer Drum (Tub) & Dampers (2)
Lift drum out of tub
Showing drum and tub parts
Bearing and drum shaft
NOTE: Rear drum bearings are
factory press fit into rear outer tubs
and cannot be removed or serviced.
