Rev 0 (1/17/08)
18
WFMC Service Tips
WFMC Service Tips
–
–
Test Program (1B): Starting
Test Program (1B): Starting
WFMC64/84 Test Program
WFMC64/84 Test Program
WFMC64/84 washer test programs self-diagnose problems, including listing the last 8 fault codes
from the control module
& the last 16 fault codes from the motor control. The tests are easy to
use, speeding up and simplifying diagnosing washer issues.
Entering & using WFMC64/84 test programs:
• To reset, rotate cycle selector knob to Off position.
• To enter test program
, push and hold Menu and Select buttons at the same time, then rotate cycle
selector knob ccw to Permanent Press Cold position. Hold Menu and Select buttons until P1:
Errors shows in display.
• To select tests
, push Menu button (to scroll through tests) until desired test shows in display (P1 -
P17) - Start/Pause light will flash.
• To start tests
, push Start/Pause button while its light is flashing -- light stays lit when test has
started. To end tests
, push Menu button.
• To exit test program, rotate cycle selector knob to Off position.
NOTE: Door locks
for all water fill and
drain tests.
HINT: If
Start/Pause light
doesn’t come on for
some tests, door is
open. Turn off
washer, then close
door.
WFMC84
P1:ERRORS
